3.96mm Molex Wafer 0.156 inch Pitch Vertical DIP for HVAC System Controller
3.96mm Molex Wafer 0.156 inch Pitch Vertical DIP for HVAC System Controller
Product Specifications
Current Rating3 Amp
Insulator Resistance5000 Megohms Min
Dielectric WithstandingAC 1000 V
No. of Positions2-15Pin
OrientationVertical
Contact MaterialCopper Alloy
Insulator MaterialOptional: PBT,PA6T,PA9
Flame RatingUL 94V-0
Plating OptionTin
Insulator HighOptional
Product Description
This 3.96mm Pitch Wafer Connector is a heavy-duty wire-to-board solution specifically engineered for industrial power supplies, home appliances, and LED driver modules. The 0.156-inch wide pitch design provides superior electrical insulation and supports high current loads of up to 7A, ensuring reliable power distribution on critical control boards. Available in vertical and right-angle configurations, these headers offer engineers flexibility for side-entry or top-entry wiring in narrow enclosures like washing machine controllers or HVAC units. The secure friction-lock design ensures a stable connection even under mechanical vibration and thermal stress in demanding industrial environments.
Key Features
- 0.156" (3.96mm) pitch for standard PCB layouts
- Customize pins, pitch,height,length
- Compliance with REACH, ISO, RoHS
- High Signal Integrity: Precision-engineered contacts provide reliable electrical performance for high-speed signal and data transmission.
- Fully automated production for consistent quality
- 100% CCD visual inspection to ensure defect-free products
