Low-Profile Overmolded Right-Angle 3-Pin Flat Ribbon Connector with Pre-Stripped Pigtail Wires for Slim Enclosures
Low-Profile Overmolded Right-Angle 3-Pin Flat Ribbon Connector with Pre-Stripped Pigtail Wires for Slim Enclosures
Product Specifications
Product Description
This product is an ultra-slim Low-Profile Overmolded Right-Angle 3-Pin Flat Ribbon Pigtail Assembly. It features a 3-pin micro-pitch connector completely encapsulated within a solid matte-black injection overmold head that exits the cable at a strict 90-degree angle. The integrated cable consists of a thin-wall, 3-conductor flat parallel bonded ribbon wire terminating in precision micro-stripped and tinned exposed leads.
-
Target Application Scenarios: Exclusively engineered for Slim LED Lighting Tracks & Linear Light Bars where wires must fit inside low-clearance aluminum extrusions. It is highly valued within Handheld Consumer Electronics (such as mobile scanners, payment terminals, and sleek smart tablets), automated motorized window blinds, and Capacitive Touch Panels where cabling must hide directly behind thin screen bezels.
-
Technical Pain Points Solved: Forcing a standard straight connector or round multi-core cable into slim enclosures requires sharp wire folding that leads to quick wire fatigue, insulation splitting, and broken solder contacts. This right-angle molded head directs wires perfectly flush to the mounting surface, eliminating geometric strain. Furthermore, standard cables create thick wire bulges that prevent slim device covers from closing properly; our flat parallel ribbon wire runs flat along the chassis walls, preserving an incredibly thin stacking height profile while the hermetic overmold shell keeps airborne moisture and dust completely away from the inner contact pins.
Key Features
- Low-clearance overmolded head protects internal pin joints from bending fatigue.
- Sleek bonded ribbon cable profile routes easily beneath PCBs or down narrow tracks.
- Injection overmold completely isolates internal wiring from airborne contaminants.
- Speeds up hand-soldering assembly operations onto tight PCB landing pads.
- Full-black cosmetic appearance blends cleanly into modern dark component housings.
